Innovative automatic safety door lock. Easy but safe – on closing, the lid is automatically locked by a circumferential ring system. A special lip seal made of heatresistant silicone provides reliable tightness; the more the steam pressure increases, the tighter the seal becomes – without the need for additional compressed air or other media! The lid also opens easily – either at the push of a button or automatically at the end of a program. This facilitates the autoclaving procedure when items that have been sterilized have to cool before being removed. The door-locking system is temperature dependent – according to national and international standards. Also, the door remains locked as long as there is excess pressure in the chamber. The lid, like other parts of the pressure vessel and housing, is made of stainless steel. The attractive faceplate of the lid, which also contains the control panel, display and part of the control technology, is made of heatresistant and insulated plastic. There is thus no risk of the operator coming into contact with hot components of the system. |
|
|||||||||||
|
||||||||||||
| Pressure-safe up
to 5 bar/150 °C. Tomorrow's requirements are catered for in today's design! The Systec V-Series autoclaves are the first of its kind to be designed for higher pressures and temperatures. The standard pressure chamber is designed to cope with 5 bar/150 °C. If the expanded pressure and temperature model is selected as an option, all control and safety components are adapted to the higher temperature and pressure. This option may be fitted retrospectively. Systec V-Series autoclaves are equipped ex-factory for sterilization temperatures up to 140 °C and a pressure of 4 bar. |
||||||||||||
| Controls – new generation. Microprocessor and software The Systec V-Series autoclaves have “comprehensive intelligence”: Pressure control is via an electronic pressure transducer. In addition, there is a flexible temperature sensor in the sterilization chamber or in a reference vessel (in the case of liquids) and a further sensor at the coldest part of the chamber, the condensate outlet. The microprocessor, specially developed for our laboratory autoclaves, controls all relevant functions such as steam pressure, temperature and sterilization time as well as options such as rapid cooling, pre- and post-vacuum and drying. |
|
|||||||||||||
| Menu-presented instructions in text form These can be selected from German, English, French, Spanish and Italian. Other languages are available as options. Large, easy- to-read display. Membrane keyboard with acoustic confirmation signal. Ergonomically located – everything is logical and easy to operate. |
||||||||||||||
| Immediate documentation Optional, with integrated printer for program type, batch number, date, time, temperature, pressure and sterilization phase. |
|
|||||||||||||
| Documentation, dialog and
diagnosis via PC Includes a standard RS 232 interface for direct connection to a PC. Special software for use with Windows optional. Suitable for documentation of all process data including relevant diagrams. In addition, dialog for adapting programs, changing parameters, calibrating and adjusting. Dis-tant diagnosis via modem is also possible. |
||||||||||||||
|
Design – pure innovation! High, all-round quality!
|
|
|||||||||||||
|
Further standard features: |
|
Vertical autoclaves Systec V-Series | |||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||
| All types: heating power 9 KW,
voltage 380 – 400 V, 50/60 Hz, 16 A. Modifications to other voltage as well as single phase operation available on request.
